The Virnig Hydraulic Adjustable Pallet Fork is a heavy‑duty skid steer attachment that lets you change pallet widths from inside the cab, boosting efficiency for loading, unloading, and material handling on any job site.

• Hydraulic width adjustment: Simultaneously adjust the tines from 8" to 38" wide without leaving the cab, aligning with pallet sizes quickly and safely.
• Universal skid steer mounting hoses, couplers & fittings: Ready to install with everything you need for a straightforward hookup, reducing setup time.
• High-visibility brickguard: Enhanced operator visibility for safer operation, especially in busy work zones.
• Angled mount plate: Optimized for reliable performance on typical skid loader configurations, improving stability across applications.
• ITA Class II forged tines: Robust, load-rated at 5,500 lbs per pair for dependable pallet handling under demanding conditions.
• 1 9/16" diameter shaft: Sturdy core designed to withstand repetitive lifting and fork placement.
• One-step and hardware to install on either side: Flexible installation options to fit your preferred mounting orientation.
• Worldwide compatibility: Same frame supports USA and Global Tines for versatile, long‑term use.
• Frame and overall dimensions: Frame width 50.1", overall height 40.1" for a compact footprint on most setups.
• Tine specifications: Tine length 48", tine thickness 1.5", min tine space 7.8" and max tine space 38.2" to handle a wide range of pallet configurations.
• Weight and capacity: Weighs 705 lbs with a 5,500 lbs capacity, providing a solid balance of strength and maneuverability.
• Recommended loader capacity: Suitable for machines with ROC greater than 1,500 lbs, ensuring appropriate performance across typical skid steer workloads.

This hydraulic adjust pallet fork is designed for professionals who need versatile pallet handling without compromising operator safety or efficiency. Use it to quickly switch between narrow pallet loads in warehouse aisles and wider pallets on loading docks, all while staying seated in the cab. The forged tines and robust frame are built to endure daily use in construction, farming, and industrial settings, making it a reliable partner for growing workloads and varied pallet dimensions.

Frame Width (in)	50.1
Overall Height (in)	40.1
Tine Length (in)	48.0
Tine Thickness (in)	1.5
Min Tine Space (in)	7.8
Max Tine Space (in)	38.2
Weight (lbs)	705
Capacity (lbs)	5500
