Virnig V70 Tree Disc Mulcher for Skid Steer
Virnig V70 Tree Disc Mulcher for Skid Steer
The Virnig V70 Tree Disc Mulcher is a heavy-duty skid-steer attachment designed to rapidly mulch brush and trees, turning up to 14 inches of material into usable mulch. It’s built for forestry contractors, land-clearing crews, and municipalities that need efficient, high-volume clearing with reliable performance.
- Cutting width: 60" cut width with a 70" overall width for wide, consistent mulching in open spaces and along trails.
- Overall dimensions: 70" (W) x 40.5" (H) x 77.5" (D) ensuring compatibility with a range of skid-steer loaders.
- Disc and balance: Fully-machined Quadco® disc that is perfectly balanced for smooth operation and long life.
- Teeth system: Bolt-on steel tooth mounts with four-sided rotatable and replaceable teeth; carbide teeth available for extended wear life.
- Teeth configuration: 3 deck-mounted teeth with a recutter bar to achieve a finer finish on mulch.
- Deck and construction: 3/8" Grade 80 interior deck weldment provides strong, durable support; replaceable push bar, chute, and deflector for easy maintenance.
- Chute options: Two chute styles available—standard or open—to adapt to material flow and site conditions.
- Power and hydraulics: Requires a high-flow loader with 30–50 GPM; max operating pressure 4,200 PSI; Bent-axis piston motor with relief valves; motor guard & spindle guard included.
- Safety: Do not operate the mulcher without a shatterproof cab on the loader for operator protection.
- Weight and loader compatibility: Approximately 2,710 lbs; recommended loader capacity greater than 2,800 lbs.
- Disc tip speeds: Flow-rate dependent tip speeds from 11,155 to 16,460 FPM, maximizing cutting efficiency at higher GPMs.
With the V70, you gain fast, controlled mulching capability that reduces manual clearing time and delivers uniform mulch ready for soil cover. The carbide-ready tooth system and recutter bar produce a cleaner finish, while replaceable wear parts minimize downtime. The dual chute options and robust guard features help you tailor performance to your site and protect critical components. This attachment is ideal for crews handling forestry thinning, rights-of-way maintenance, and challenging brush clearing tasks where reliable, high-capacity mulching is essential.
| MODEL | TDM60 |
| Cut Width (Inches) | 60.0 |
| Overall Width (Inches) | 70.0 |
| Overall Height (Inches) | 40.5 |
| Overall Depth (Inches) | 77.5 |
| Deck Height (Inches) | 11.0 |
| Push Bar Height (Inches) | 40.5 |
| Minimum Cut Height (Inches) | 2.1 |
| Cutting Capacity, Diameter (Inches) | 14.0 |
| Number of Teeth: Top / Bottom / Outside | 12 / 20 / 12 |
| Maximum Disc Thickness (Inches) | 1.25 |
| Deck Thickness: Top, Side / Inside (Inches) | 0.25 / 0.375¹ |
| Recommended Flow Rate (GPM) | 30-50 High Flow Only |
| Approximate Weight (Pounds) | 2710 |
| Recommended Loader Capacity | Greater than 2800 pounds |
| MODEL | 30 GPM | 35 GPM | 40 GPM | 45 GPM | 50 GPM | |||||
| TDM60-HF45 | 11,155 | 13,006 | 14,875 | 16,730 | – | |||||
| TDM60-HF50 | – | – | – | 14,810 | 16,460 | |||||
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Virnig V70 Tree Disc Mulcher for Skid Steer
Virnig V70 Tree Disc Mulcher for Skid Steer
Virnig V70 Tree Disc Mulcher for Skid Steer
The Virnig V70 Tree Disc Mulcher is a heavy-duty skid-steer attachment designed to rapidly mulch brush and trees, turning up to 14 inches of material into usable mulch. It’s built for forestry contractors, land-clearing crews, and municipalities that need efficient, high-volume clearing with reliable performance.
- Cutting width: 60" cut width with a 70" overall width for wide, consistent mulching in open spaces and along trails.
- Overall dimensions: 70" (W) x 40.5" (H) x 77.5" (D) ensuring compatibility with a range of skid-steer loaders.
- Disc and balance: Fully-machined Quadco® disc that is perfectly balanced for smooth operation and long life.
- Teeth system: Bolt-on steel tooth mounts with four-sided rotatable and replaceable teeth; carbide teeth available for extended wear life.
- Teeth configuration: 3 deck-mounted teeth with a recutter bar to achieve a finer finish on mulch.
- Deck and construction: 3/8" Grade 80 interior deck weldment provides strong, durable support; replaceable push bar, chute, and deflector for easy maintenance.
- Chute options: Two chute styles available—standard or open—to adapt to material flow and site conditions.
- Power and hydraulics: Requires a high-flow loader with 30–50 GPM; max operating pressure 4,200 PSI; Bent-axis piston motor with relief valves; motor guard & spindle guard included.
- Safety: Do not operate the mulcher without a shatterproof cab on the loader for operator protection.
- Weight and loader compatibility: Approximately 2,710 lbs; recommended loader capacity greater than 2,800 lbs.
- Disc tip speeds: Flow-rate dependent tip speeds from 11,155 to 16,460 FPM, maximizing cutting efficiency at higher GPMs.
With the V70, you gain fast, controlled mulching capability that reduces manual clearing time and delivers uniform mulch ready for soil cover. The carbide-ready tooth system and recutter bar produce a cleaner finish, while replaceable wear parts minimize downtime. The dual chute options and robust guard features help you tailor performance to your site and protect critical components. This attachment is ideal for crews handling forestry thinning, rights-of-way maintenance, and challenging brush clearing tasks where reliable, high-capacity mulching is essential.
| MODEL | TDM60 |
| Cut Width (Inches) | 60.0 |
| Overall Width (Inches) | 70.0 |
| Overall Height (Inches) | 40.5 |
| Overall Depth (Inches) | 77.5 |
| Deck Height (Inches) | 11.0 |
| Push Bar Height (Inches) | 40.5 |
| Minimum Cut Height (Inches) | 2.1 |
| Cutting Capacity, Diameter (Inches) | 14.0 |
| Number of Teeth: Top / Bottom / Outside | 12 / 20 / 12 |
| Maximum Disc Thickness (Inches) | 1.25 |
| Deck Thickness: Top, Side / Inside (Inches) | 0.25 / 0.375¹ |
| Recommended Flow Rate (GPM) | 30-50 High Flow Only |
| Approximate Weight (Pounds) | 2710 |
| Recommended Loader Capacity | Greater than 2800 pounds |
| MODEL | 30 GPM | 35 GPM | 40 GPM | 45 GPM | 50 GPM | |||||
| TDM60-HF45 | 11,155 | 13,006 | 14,875 | 16,730 | – | |||||
| TDM60-HF50 | – | – | – | 14,810 | 16,460 | |||||
Original: $34,897.00
-65%$34,897.00
$12,213.95Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Virnig V70 Tree Disc Mulcher for Skid Steer
The Virnig V70 Tree Disc Mulcher is a heavy-duty skid-steer attachment designed to rapidly mulch brush and trees, turning up to 14 inches of material into usable mulch. It’s built for forestry contractors, land-clearing crews, and municipalities that need efficient, high-volume clearing with reliable performance.
- Cutting width: 60" cut width with a 70" overall width for wide, consistent mulching in open spaces and along trails.
- Overall dimensions: 70" (W) x 40.5" (H) x 77.5" (D) ensuring compatibility with a range of skid-steer loaders.
- Disc and balance: Fully-machined Quadco® disc that is perfectly balanced for smooth operation and long life.
- Teeth system: Bolt-on steel tooth mounts with four-sided rotatable and replaceable teeth; carbide teeth available for extended wear life.
- Teeth configuration: 3 deck-mounted teeth with a recutter bar to achieve a finer finish on mulch.
- Deck and construction: 3/8" Grade 80 interior deck weldment provides strong, durable support; replaceable push bar, chute, and deflector for easy maintenance.
- Chute options: Two chute styles available—standard or open—to adapt to material flow and site conditions.
- Power and hydraulics: Requires a high-flow loader with 30–50 GPM; max operating pressure 4,200 PSI; Bent-axis piston motor with relief valves; motor guard & spindle guard included.
- Safety: Do not operate the mulcher without a shatterproof cab on the loader for operator protection.
- Weight and loader compatibility: Approximately 2,710 lbs; recommended loader capacity greater than 2,800 lbs.
- Disc tip speeds: Flow-rate dependent tip speeds from 11,155 to 16,460 FPM, maximizing cutting efficiency at higher GPMs.
With the V70, you gain fast, controlled mulching capability that reduces manual clearing time and delivers uniform mulch ready for soil cover. The carbide-ready tooth system and recutter bar produce a cleaner finish, while replaceable wear parts minimize downtime. The dual chute options and robust guard features help you tailor performance to your site and protect critical components. This attachment is ideal for crews handling forestry thinning, rights-of-way maintenance, and challenging brush clearing tasks where reliable, high-capacity mulching is essential.
| MODEL | TDM60 |
| Cut Width (Inches) | 60.0 |
| Overall Width (Inches) | 70.0 |
| Overall Height (Inches) | 40.5 |
| Overall Depth (Inches) | 77.5 |
| Deck Height (Inches) | 11.0 |
| Push Bar Height (Inches) | 40.5 |
| Minimum Cut Height (Inches) | 2.1 |
| Cutting Capacity, Diameter (Inches) | 14.0 |
| Number of Teeth: Top / Bottom / Outside | 12 / 20 / 12 |
| Maximum Disc Thickness (Inches) | 1.25 |
| Deck Thickness: Top, Side / Inside (Inches) | 0.25 / 0.375¹ |
| Recommended Flow Rate (GPM) | 30-50 High Flow Only |
| Approximate Weight (Pounds) | 2710 |
| Recommended Loader Capacity | Greater than 2800 pounds |
| MODEL | 30 GPM | 35 GPM | 40 GPM | 45 GPM | 50 GPM | |||||
| TDM60-HF45 | 11,155 | 13,006 | 14,875 | 16,730 | – | |||||
| TDM60-HF50 | – | – | – | 14,810 | 16,460 | |||||
