Virnig v20 High Capacity Dirt Bucket for Mini Skid Steer
The Virnig v20 High Capacity Dirt Bucket is designed for mini skid steers that tackle large volumes of dirt and debris. With a tall back that increases capacity, it helps you move more material per pass on busy sites.
- Available Widths: 36", 42", 44", 48", 54" options (CHCB36āCHCB52) with inside widths of 34.6", 40.6", 42.6", 46.6", 52.6" respectively.
- Tall Back Design: Increases struck and heaped capacity to hold more material per lift, reducing the number of cycles needed.
- Heavy-Duty Construction: 1/4" steel shell and 3/16" side plates, with a 0.25" shell thickness and 0.19" side plates, plus a 70Ā° bucket back angle for strong digging and back-dragging performance.
- Grading Bend: Grading bend engineered for optimal reverse grading, aiding smooth filling and leveling as you pull back and dump.
- Weld-On Edge: 1/2" x 4" weld-on edge provides durable wear resistance for repeated scraping and cutting through tough material.
- Capacity & Weight by Width: Struck / Heaped capacities range from 7.2/8.6 ftĀ³ (36") up to 10.8/13.0 ftĀ³ (54"); approximate weights from 235 lb to 315 lb depending on width; recommended loader capacity under 1650 lb.
If youāre maximizing productivity with a compact loader, the Virnig v20 bucket delivers substantial capacity without overburdening the machine. Its robust build, precise edge, and thoughtful geometry help you tackle bulk dirt, fill, and grading tasks more efficiently on jobsites, landscaping projects, and utility work.
| MODEL | CHCB36 | CHCB42 | CHCB44 | CHCB48 | Ā CHCB52 |
| Width: Overall / Inside (Inches) | 36.0 / 34.6 | 42.0 / 40.6 | 44.0 / 42.6 | 48.0 / 46.6 | 54.0 / 52.6 |
| Overall Height (Inches) | 20.8 | 20.8 | 20.8 | 20.8 | 20.8 |
| Depth: Overall / Inside (Inches) | 32.7 / 29.3 | 32.7 / 29.3 | 32.7 / 29.3 | 32.7 / 29.3 | 32.7 / 29.3 |
| Capacity: Struck / Heaped (Cubic Feet) | 7.2 / 8.6 | 8.4 / 10.1 | 8.8 / 10.6 | 9.6 / 11.5 | 10.8 / 13.0 |
| Bucket Back Angle (Degrees) | 70 | 70 | 70 | 70 | 70 |
| Shell Thickness (Inches) | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 |
| Side Plate Thickness (Inches) | 0.19 | 0.19 | 0.19 | 0.19 | 0.19 |
| Approximate Weight (Pounds) | 235 | 260 | 270 | 290 | 315 |
| Recommended Loader Capacity | Less than 1650 pounds | Less than 1650 pounds | Less than 1650 pounds | Less than 1650 pounds | Less than 1650 pounds |
