BLUE DIAMOND 4-in-1 Bucket for Skid Steer

Features

• 4-in-1 versatility: grapple for logs or debris, push dirt with a dozer-like blade, dig with the bucket, or back-drag with the open bucket like a box blade.
• Two powerful hydraulic cylinders drive all four functions; pivot points are greaseable for long-lasting performance.
• Pilot-operated check valve helps prevent drifting, enhancing control on uneven terrain.
• Protected hose routing keeps lines out of pinch points; oversize pins and bushings with grease fittings are designed for durability.
• Optional configurations: teeth or bolt-on-edge; front bolt-on-edge available; weld-on shanks and teeth are available to match your job needs.
• Standard features include protected hoses and easy maintenance access for reliable, years-long service.
• Available widths from 60" to 84" with either Smooth Edge or Teeth variants to suit loader size and material.

Benefits

• Maximize machine versatility: one attachment replaces multiple tools, reducing downtime and tool changes on the job site.
• Improve material handling and site finish: grapple handles debris and logs, while the blade and bucket work together for grading and back-dragging precision.
• Enhance control and safety: drift resistance and thoughtfully routed hoses minimize sudden movements and pinch points.
• Durable, low-maintenance design: oversized components and grease fittings keep critical parts accessible and protected for years of service.
• Flexible for various trades: ideal for landscaping, construction, forestry cleanup, and property maintenance with options that adapt to site conditions.
• Practical care tips: regularly grease pivot points, inspect hoses for wear, and ensure hoses are routed away from pinch points to extend life.

Part Number	Model	Struck Capacity	Weight
108780	66" 4-in-1, W/Smooth Edge	13.9 cu ft	862 lbs
108785	72" 4-in-1, W/Smooth Edge	15.2 cu ft	908 lbs
108790	78" 4-in-1, W/Smooth Edge	16.5 cu ft	979 lbs
108795	84" 4-in-1, W/Smooth Edge	17.7 cu ft	1,004 lbs
108776	60" 4-in-1, W/Teeth	12 cu ft	855 lbs
108781	66" 4-in-1, W/Teeth	13.9 cu ft	750 lbs
108786	72" 4-in-1, W/Teeth	15.2 cu ft	981 lbs
108791	78" 4-in-1, W/Teeth	16.5 cu ft	959 lbs
108796	84" 4-in-1, W/Teeth	17.7 cu ft	932 lbs
